Product Details:

X

Product Description

The Welding Positioner are positive drive & includes mounting flange, drive & tilt mechanism. Apart from this they are manufactured using high grade components that are procured from our trusted vendors. These positioner comes in both standard & programmable models. The Welding Positioner are made for welding purposes and are driven by a low voltage motor and gear. They comes in various speed and are electronically controlled using tachometer. Further they are also tested by our quality assurance team to ensure they are safe to use. They can be availed from us at reasonable price point.

Specification :

15t Welding Positioner Specification :

Model :

PE15

Tilt Capacity :

15 metric ton at 300mm (centre of gravity)

Tilt Range :

0 to 135 degrees

Tilt Speed :

135 degree in 120 seconds

Rotation Capacity :

15 metric ton at 300mm

Rotation Speed :

0.01 to 1.0 rpm

Table Diameter :

1800mm


3t Welding Positioner Specification :

Model :

LPE3

Tilt Capacity :

3 metric ton at 300mm (centre of gravity)

Tilt Range :

0 to 135 degrees

Tilt Speed :

135 degree in 50 seconds

Rotation Capacity :

3 metric ton at 300mm

Rotation Speed :

0.1 to 1 rpm

Table Diameter :

1200mm


250kg Welding Positioner Specification :

Model :

LPE0.25

Tilt Capacity :

250kg at 300mm (centre of gravity)

Tilt Range :

0 to 135 degrees

Tilt Speed :

135 degrees in 30 secs

Rotation Capacity :

250kg @ 300mm

Rotation Speed :

0 to 4 rpm

Table Diameter :

500mm
